5094-OF8 and 5094-OF8XT Analog Current/Voltage Output Modules

This figure shows a wiring diagram for the 5094-OF8 and 5094-OF8XT modules when used in current mode. You must connect a 24V DC

power source to the left SA+/– terminals to provide field-side power.

5094-OF8 and 5094-OF8XT Wiring Diagram — Current Mode。
